UltraRipper™

K-Line Ag’s UltraRipper™ is built for large-scale broadacre soil renovation, penetrating hardpans up to 750 mm deep while minimising disturbance at the soil surface. Its narrow-profile shanks and low-angle blade design lift and shatter compacted soil without unnecessary inversion, helping maintain natural soil horizons and keep valuable topsoil where it belongs.
Special Offers
Find a Dealer
Find a Dealer

Built to shatter the deepest hardpans

The K-Line Ag UltraRipper™ is designed to tackle deep soil compaction across broadacre operations.

Working down to 750 mm, the UltraRipper™ lifts and shatters hardpans without unnecessary soil inversion. Its narrow-profile shank reduces draft and minimises surface disturbance, helping maintain soil structure while requiring less power to get the job done.

An accumulator-cushioned hydraulic breakout system provides fast recoil and controlled return, helping protect the machine while maintaining performance in demanding conditions.

More Information
Find a Dealer

Deep ripping performance with minimal surface disturbance

Compacted soil can restrict root development, moisture movement and access to nutrients. The UltraRipper™ is engineered to break through these deep hardpans while leaving the upper soil profile as undisturbed as possible.

The narrow-profile shanks and low blade entry angle lift and fracture compacted soil rather than unnecessarily turning it over. This helps preserve natural soil horizons and keeps valuable topsoil at the surface.

Adjustable shank length allows the machine to be configured for the required breakout and underframe clearance, while the hydraulic breakout system combines fast release with a controlled return to protect the frame in tough conditions.

Rear mounting points also provide provision for inclusion plates and other soil amelioration accessories.

Powerful deep ripping, efficiently delivered

  • Working depth up to 750 mm
  • Narrow-profile shanks for reduced draft
  • Minimal soil surface disturbance
  • Lifts and shatters compacted soil without unnecessary inversion
  • Low blade entry angle
  • Accumulator-cushioned hydraulic breakout
  • Fast release and controlled return
  • Adjustable shank length
  • Provision for soil amelioration accessories
  • Available in 6.5 m rigid and 12.5 m folding configurations

Features & Benefits

The UltraRipper™ is engineered for deep soil renovation with minimal surface disturbance. Its narrow-profile shanks and low-angle blade design reduce draft while lifting and shattering hardpans up to 750 mm deep without unnecessary soil inversion.

An accumulator-cushioned hydraulic breakout system protects the machine in tough conditions, while adjustable shank length provides the flexibility to achieve the right breakout and underframe clearance for the job.

Options

Two sizes for large-scale broadacre operations

Choose the UltraRipper™ configuration that best suits your tractor and operation.

3660T

Trailing, Rigid

  • 6.5 m operating width

  • 13 shanks

  • 500 mm shank spacing

  • 400+ hp tractor requirement

3612P

Trailing, Folding

  • 12.5 m operating width

  • 25 shanks

  • 500 mm shank spacing

  • 600+ hp tractor requirement

More Information
Find a Dealer

Specifications

ModelOperating WidthTransport WidthNo. of ShanksShank SpacingTractor Power
3660T Trailing, Rigid
6.5 m
6.6 m
13
500 mm
400+ hp
3612P Trailing, Folding
12.5 m
7.2 m
25
500 mm
600+ hp
Specifications are subject to change without prior notice.

Ultra-Wide. Ultra Deep. Ultra Low Draft.

Built for the demands of broadacre soil renovation, the UltraRipper™ combines deep working capability, low-draft shank design and robust hydraulic breakout protection to tackle the toughest hardpans with minimal surface disturbance.
